Function Overview:

1. Adaptive AC and DC working power supply: AC 100V~240V (50Hz), DC 100V~240V.

2. Can communicate and charge with 8/12 smart keys simultaneously.

3. It can automatically recognize whether the key is in place.

4. It can automatically transmit or synchronize key data.

5. It can be connected to a PC through a USB interface and send and receive operation data to the smart key.

6. Built in communication module, which can remotely authorize unlocking or receive operation data from the smart key through the smart device lock management platform.

Technical parameters:

1. Rated voltage: 220 V ± 15%

2. Number of smart keys that can be stored and charged simultaneously: 8/12

3. Communication method with the smart key: MiniUSB2.0 is used

4. Communication baud rate: 9600bps

5. Rated output voltage: 5V

6. Rated output current: 1000mA
